FOTON Tunland – Export Specification
eTUNLAND — Export Specification
100% electric pickup — 5 configurations, 16 export markets.
- 100kWPower
- 176NmTorque
- 3unitsPer 40′ HQ
- 5configsConfigurations
Built for the roads your customers actually drive
Every configuration above is a real, orderable export specification — homologated for the markets listed, with the emission standard and steering your country requires. We ship in 40’HQ containers from Qingdao or Shanghai.
Configurations
Filter by drive, steering, gearbox or fuel to narrow the list below.
TZ180XS130/FTTBP150C · / · 4×4 · Double cab
100/150 kWPower
4×4Drive
/Transmission
1520 mmCargo box
3200 kgGVW
3Per 40′ HQ
| Engine | TZ180XS130/FTTBP150C · · 100/150 kW · 176/340 Nm |
|---|---|
| Fuel | Electric |
| Transmission | / |
| Drive | 4×4 |
| Cab / seats | Double cab · 5 |
| Steering | LHD |
| Cargo box (L×W×H) | 1520×1580×440 mm |
| GVW / curb weight | 3200 kg / 2310 kg |
| Emission | Zero emission |
| Container loading | 3 units |
Full technical specification — TZ180XS130/FTTBP150C /
| Engine & drivetrain | |
| Engine | TZ180XS130/FTTBP150C |
|---|---|
| Engine manufacturer | CATL |
| Displacement | — (electric) |
| Power | 100/150 kW |
| Torque | 176/340 Nm |
| Fuel | Electric |
| Transmission | / |
| Emission | Zero emission |
| Dimensions & weight | |
| Overall dimensions | 5340×1940×1870 mm |
| Wheelbase | 3110 mm |
| Cargo box (L×W×H) | 1520×1580×440 mm |
| GVW | 3200 kg |
| Curb | 2310 kg |
| Export & logistics | |
| Container loading | 3 units per 40′ HQ |
| Steering | LHD |
| Port | Qingdao / Shanghai, China |
| Export markets | 5 |
| Chassis & running gear | |
| Suspension | Double wishbone independent front / leaf-spring rigid rear |
| Brakes | Disc front and rear |
| Tyres | 265/65R17 |
| Fuel tank | 88.02kWh L |
TZ180XS130/FTTBP150C · / · 4×4 · Double cab
100/150 kWPower
4×4Drive
/Transmission
1520 mmCargo box
3200 kgGVW
3Per 40′ HQ
| Engine | TZ180XS130/FTTBP150C · · 100/150 kW · 176/340 Nm |
|---|---|
| Fuel | Electric |
| Transmission | / |
| Drive | 4×4 |
| Cab / seats | Double cab · 5 |
| Steering | RHD |
| Cargo box (L×W×H) | 1520×1580×440 mm |
| GVW / curb weight | 3200 kg / 2310 kg |
| Emission | Zero emission |
| Container loading | 3 units |
Full technical specification — TZ180XS130/FTTBP150C /
| Engine & drivetrain | |
| Engine | TZ180XS130/FTTBP150C |
|---|---|
| Engine manufacturer | CATL |
| Displacement | — (electric) |
| Power | 100/150 kW |
| Torque | 176/340 Nm |
| Fuel | Electric |
| Transmission | / |
| Emission | Zero emission |
| Dimensions & weight | |
| Overall dimensions | 5340×1940×1870 mm |
| Wheelbase | 3110 mm |
| Cargo box (L×W×H) | 1520×1580×440 mm |
| GVW | 3200 kg |
| Curb | 2310 kg |
| Export & logistics | |
| Container loading | 3 units per 40′ HQ |
| Steering | RHD |
| Port | Qingdao / Shanghai, China |
| Export markets | 3 |
| Chassis & running gear | |
| Suspension | Double wishbone independent front / leaf-spring rigid rear |
| Brakes | Disc front and rear |
| Tyres | 265/65R17 |
| Fuel tank | 88.02kWh L |
FTTB065 · / · 4×2 · Double cab
130 kWPower
4×2Drive
/Transmission
1520 mmCargo box
3200 kgGVW
3Per 40′ HQ
| Engine | FTTB065 · · 130 kW · 350 Nm |
|---|---|
| Fuel | Electric |
| Transmission | / |
| Drive | 4×2 |
| Cab / seats | Double cab · 5 |
| Steering | RHD |
| Cargo box (L×W×H) | 1520×1580×440 mm |
| GVW / curb weight | 3200 kg / 2300 kg |
| Emission | Zero emission |
| Container loading | 3 units |
Full technical specification — FTTB065 /
| Engine & drivetrain | |
| Engine | FTTB065 |
|---|---|
| Engine manufacturer | CATL |
| Displacement | — (electric) |
| Power | 130 kW |
| Torque | 350 Nm |
| Fuel | Electric |
| Transmission | / |
| Emission | Zero emission |
| Dimensions & weight | |
| Overall dimensions | 5340×1940×1870 mm |
| Wheelbase | 3110 mm |
| Cargo box (L×W×H) | 1520×1580×440 mm |
| GVW | 3200 kg |
| Curb | 2300 kg |
| Export & logistics | |
| Container loading | 3 units per 40′ HQ |
| Steering | RHD |
| Port | Qingdao / Shanghai, China |
| Export markets | 7 |
| Chassis & running gear | |
| Suspension | Double wishbone independent front / leaf-spring rigid rear |
| Brakes | Disc front and rear |
| Tyres | 265/65R17 |
| Fuel tank | 88.02kWh L |
FTTB065 · / · 4×2 · Double cab
130 kWPower
4×2Drive
/Transmission
1520 mmCargo box
3200 kgGVW
3Per 40′ HQ
| Engine | FTTB065 · · 130 kW · 350 Nm |
|---|---|
| Fuel | Electric |
| Transmission | / |
| Drive | 4×2 |
| Cab / seats | Double cab · 5 |
| Steering | LHD |
| Cargo box (L×W×H) | 1520×1580×440 mm |
| GVW / curb weight | 3200 kg / 2300 kg |
| Emission | Zero emission |
| Container loading | 3 units |
Full technical specification — FTTB065 /
| Engine & drivetrain | |
| Engine | FTTB065 |
|---|---|
| Engine manufacturer | CATL |
| Displacement | — (electric) |
| Power | 130 kW |
| Torque | 350 Nm |
| Fuel | Electric |
| Transmission | / |
| Emission | Zero emission |
| Dimensions & weight | |
| Overall dimensions | 5340×1940×1870 mm |
| Wheelbase | 3110 mm |
| Cargo box (L×W×H) | 1520×1580×440 mm |
| GVW | 3200 kg |
| Curb | 2300 kg |
| Export & logistics | |
| Container loading | 3 units per 40′ HQ |
| Steering | LHD |
| Port | Qingdao / Shanghai, China |
| Export markets | 5 |
| Chassis & running gear | |
| Suspension | Double wishbone independent front / leaf-spring rigid rear |
| Brakes | Disc front and rear |
| Tyres | 265/65R17 |
| Fuel tank | 88.02kWh L |
FTTB065 · / · 4×2 · Single cab
130 kWPower
4×2Drive
/Transmission
2315 mmCargo box
3200 kgGVW
3Per 40′ HQ
| Engine | FTTB065 · · 130 kW · 350 Nm |
|---|---|
| Fuel | Electric |
| Transmission | / |
| Drive | 4×2 |
| Cab / seats | Single cab · 2 |
| Steering | RHD |
| Cargo box (L×W×H) | 2315×1580×440 mm |
| GVW / curb weight | 3200 kg / 2180 kg |
| Emission | Zero emission |
| Container loading | 3 units |
Full technical specification — FTTB065 /
| Engine & drivetrain | |
| Engine | FTTB065 |
|---|---|
| Engine manufacturer | CATL |
| Displacement | — (electric) |
| Power | 130 kW |
| Torque | 350 Nm |
| Fuel | Electric |
| Transmission | / |
| Emission | Zero emission |
| Dimensions & weight | |
| Overall dimensions | 5340×1940×1870 mm |
| Wheelbase | 3110 mm |
| Cargo box (L×W×H) | 2315×1580×440 mm |
| GVW | 3200 kg |
| Curb | 2180 kg |
| Export & logistics | |
| Container loading | 3 units per 40′ HQ |
| Steering | RHD |
| Port | Qingdao / Shanghai, China |
| Export markets | 1 |
| Chassis & running gear | |
| Suspension | Double wishbone independent front / leaf-spring rigid rear |
| Brakes | Disc front and rear |
| Tyres | 265/65R17 |
| Fuel tank | 88.02kWh L |
Export markets
16 — Homologated for these markets
Homologated for export
Not yet homologated
Not yet homologated
Highlighted countries are those for which this model line holds an export homologation. Contact us to confirm the exact configuration and documentation for your market.
Full country list (16)
Brazil
Chile
Djibouti
Ethiopia
Hong Kong SAR
Indonesia
Indonesia / Malaysia / Thailand
Israel
Malaysia
Mexico
Nepal
Paraguay
Serbia
Singapore
South Africa
Thailand
Chile
Djibouti
Ethiopia
Hong Kong SAR
Indonesia
Indonesia / Malaysia / Thailand
Israel
Malaysia
Mexico
Nepal
Paraguay
Serbia
Singapore
South Africa
Thailand
eTUNLAND
Request a quotation
Tell us your destination port and quantity — we reply with FOB and CIF pricing within 24 hours, Monday to Saturday.
Send your enquiry in 30 seconds: no account, no long form.
Engineering detail
Component-level facts, as published in FOTON export material.
- ZF 8AT transmission
- Longitudinal 8-speed automatic from ZF. Carries 100 N·m more torque than a conventional 8AT, shifts 50% faster and reaches 96% transmission efficiency. Electronic parking brake (EPB) and Auto Hold are fitted on automatic models.
- Bosch ESP, 9 functions
- Latest-generation Bosch ESP integrating ABS, EBD, TCS, HBA, VDC, HBB, HHC (hill-start assist), HDC (hill descent) and BLF. It processes 30% more signals than the previous generation.
- Bosch CRDi, 3rd generation
- German high-pressure common-rail injection for high combustion efficiency and low CO₂ output, keeping the engine in its best operating range.
- BorgWarner VGT turbo
- Variable-geometry turbine: responds at low engine speed and holds boost at the top end, which reduces fuel use and NVH.
- Body and loading
- Factory cargo box with corrosion-resistant coating; rope hooks inside and outside; the cargo-box step is rated to 150 kg.
Who builds it
- 27 years of FOTON commercial-vehicle manufacturing; over 10 million vehicles sold worldwide.
- Engine joint venture with Cummins; transmission joint venture with ZF; commercial-vehicle joint venture with Daimler-Benz.
- EU WVTA certificate held since 2019.
- Number one in Chinese commercial-vehicle exports.
Source: FOTON export product material, 2024–2026
